Clamp Saddle

CODE

SIZE

D

L

H

H1

T

W

S050012

50mm x 1/2''

50

89

80

17

65

175

S050034

50mm x 3/4''

50

89

81

22

65

176

S050100

50mm x 1''

50

89

9O

28

65

185

S063012

63mm x 1/2''

63

107

98

17

72

220

S063034

63mm x 3/4''

63

107

98

23

72

223

S063100

63mm x 1''

63

107

98

24

72

225

S075012

75mm x 1/2''

75

116

113

22

82

308

S075034

75mm x 3/4''

75

116

121

30

82

314

S075100

75mm x 1''

75

116

119

28

82

314

S075114

75mm x 1 1/4''

75

116

118

28

82

313

S075112

75mm x 1 1/2''

75

116

119

29

82

330

S090012

90mm x 3/2''

90

133

131

22

85

362

S090034

90mm x 3/4''

90

133

134

24

85

364

S090100

90mm x 1''

90

133

136

28

85

367

S090114

90mm x 1 3/4''

90

133

137

28

85

367

S090112

90mm x 1 1/2''

90

133

137

29

85

374

S110012

110mm x 1/2''

110

159

151

25

92

460

S110034

110mm x 3/4''

110

159

153

25

92

463

S110100

110mm x 1''

110

159

159

30

92

465

S110114

110mm x 1 1/4''

110

159

157

30

92

465

5110112

110mm x 1 1/2''

110

159

160

32

92

472
